Usage:
Applicable to food, bottle,agricultural irrigation, etc. Product water can be used to produce drinking water.
Standards:
1. Comply with FDA attestation requirements
Description of WT-RO RO purified water equipment:
First stage pretreatment.(Sand filter)
The use of multi-medium quartz sand filters, main purpose is to remove the water contains sediment, manganese, rust, colloid material, mechanical impurities, suspended solids and other particles in the above 20UM of substances hazardous to health.
Second stage pretreatment (Carbon filter)
Activated carbon filters used to remove the pigment in the water, smell, a large number of chemical and biological organisms, reducing the residual value of water and pesticide pollution and other harmful pollutants.
Third stage pretreatment (Resin softener)
Cationic resin used for water softening, primarily to remove hardness of water. So as to effectively prevent the reverse osmosis membrane fouling. System can automatically recoil, and so is red.
Fourth stage pretreatment (Micron filter)
Particle size in water to remove fine particles, sand filters can remove very small colloidal particles in the water, so that the turbidity reached 1 degree.
RO system
The core equipment of water pump is imported and the membrane film is imported from Hydranautics in America. It is equipped with full set of clean unit. It has the features of simple structure, convenient operation and high technological level.
Functions of each part for RO purified water equipment:
1.Raw water tank: store raw water, control raw water and subside impurities
2.Raw water pump: raw water pressurization, provide power to pre-treatment system, water intake and cleaning
3.MMF: primarily to remove sand, impurities, suspended solids and other particles in water, reduce turbidity
4.ACF: to absorb color, odor and residual chlorine
5.Dosing device: make use of specified resin for softened water to replace calcium and magnesium ions and reduce water hardness
6.Cartridge filter: prevent large grained impurities from entering reverse osmosis membrane and damaging membrane
7. Reverse osmosis main machine: The Reverse Osmosis device is an equipment to purify the saline water with the action of pressure difference of semi-permeable membrane. It is called reverse osmosis, as it is counter to natural penetration direction. Difference materials have different osmotic pressures.
The reverse osmosis can remove more than 97% of the soluble salt and above 99% of the colloid, microorganism, particles and organic materials, becoming the best first-choice choice equipment in the engineering of modern purified water, highly purified water and space water (super-purified water). The most highlighted features are low energy consumption, no pollution, simple technique, high-quality water and convenient operation and maintenance
8. UV sterilizer: by strong UV light, various microorganisms such as bacteria and virus in water are destroyed all of a sudden
Design advantages of WT-RO RO purified water equipment:
A. Modular design method, can be individually assembled according to different customer’s requirements. The whole system adopts all stainless steel configuration, operates stable, delicate and beautiful.
B. Equipped with all stainless steel raw water tank, intermediate water tank, specialized purified water tank, stable and beautiful.
C. Equipped with 304/316L specialized purified water tank and digital liquid level control, rotary spray cleaning and air-breathing apparatus
D. Adopts imported low pressure reverse osmosis membrane of high desalination rate, stable operation and 20% energy consumption reduction
E. Equipped with imported PH regulator and online detecting system to adjust PH and prevent CO2 from affecting product water quality
F. Equipped with UV sterilization system and terminal ultrafiltration device
G.The control system is fully automatic and main parts adopt imported components of high stability and easy operation. Purified water conveying is equipped with constant pressure water supply system
I. Equipped with product water quality electrical conductivity excessive alarm controlling system, to avoid exceed standard water caused by machine halt to enter water tank
J. Main materials all adopt international famous brand in industry to make sure quality and quantity, and optimum allocation design
Packaging & Shipping
Packaging details: customized/wooden package
Delivery Details: 15--60 days based on capacity and quantity
Our Services
12 months warranty and free maintainance cost
24 after-sales service online
Whole life free technical support
Trace for order until you get the goods
Engineer available to go abroad for installation and training
