Basic Info.
Working Pressure
Low Pressure Pump
Influent Type of Impeller
Single Suction Pump
Position of Pump Shaft
Vertical Pump
Pump Casing Combined
Horizontal Split Pumps
Mounting Height
Since Irrigation Centrifugal Pumps
Impeller
Open
Usage
Pump
Body Material
SS304, SS316L
Impeller Surface
Mirror or Matte
Sealing Material
Sic/C/Viton
Qualified Certificate for Seal
FDA
Raw Material
Forging or Casting
Processing Machine
LG Mazak CNC Machine
Inner Surface Finish
Ra 0.5
External Surface Finish
Ra 0.8
Transport Package
Wooden Case
Specification
0.55KW-11KW
Origin
China, Wenzhou
HS Code
8413190000
Production Capacity
300sets/Month
Product Description
Stainless Steel Sanitary Rotary Rotor Lobe Pump, Self Priming CIP Liquid Ring Pump, Centrifugal Pump
Our centrifugal pump is a sanitary pump that meets the highest sanitary requirements for use in the food-processing and pharmaceutical, dairy, milk, bear industries.
Some of its uses include processes in the brewing, dairy and beverage industries, and with the appropriate options it can also be used in complex applications such as
Evaporators, concentrators, distillation towers, decanting of syrups, and purified-water loops in the pharmaceutical industry.
Housed inside the casing, the impeller rotates in conjunction with the pump shaft. With this arrangement, the impeller blades convey energy to the fluid in the form of
Kinetic energy and pressure energy.
Due to the special design of the pump casing and impeller, the BOGP centrifugal pump has much higher pressure than standard centrifugal pump.
Features:
Motor: 0.55-22Kw
Impeller: Open type
Rotating speed: 2900rpm(50Hz)or 3600rpm(60Hz)
Flow: 1.5-120/h
Lift: 0-75m
MAX pressure: 7Bar
MAX temperature: 120degree
Connection: Clamp, Thread, Flange, Welding
Standard: DIN, SMS, 3A, ISO, IDF, RJT
We have open impeller and close impeller types. And according to customers' requirements, we design movable type and explosion type.
Design and Standard:
Design based on 3A hygienic standard
Adjustable stainless steel leg
Mechanical seal: Single mechanical seal and double mechanical seal
Material:
Motor housing: Cold rolled stainless steel plate
Investment casting impeller: AISI 304/316L
Contact parts with material: EPDM
Gasket: SSC-Sic/EPDM
Internal surface: Ra≤ 0.8um
External surface: Mirror polish
